High-precision wafer measurement meets surging demand from AI and data centers

Rigaku Corporation, a global solution partner in X-ray analytical systems and a group company of Rigaku Holdings Corporation (headquarters: Akishima, Tokyo; CEO: Jun Kawakami; hereinafter “Rigaku”) has launched the XTRAIA MF-3400, an instrument used in semiconductor manufacturing processes to measure the thickness and composition of wafers. The XTRAIA MF-3400 will significantly enhance productivity in the rapidly growing semiconductor market by enabling high-accuracy evaluation of materials essential for mass production of next-generation memory chips and high-speed AI devices.

This press release features multimedia. View the full release here: https://www.businesswire.com/news/home/20251204537975/en/

XTRAIA MF-3400

As generative AI and data centers continue to expand, demand is rising for high-performance, energy-efficient semiconductors capable of processing vast volumes of data. Consequently, semiconductor structures are becoming more complex, delicate, and three-dimensional, with a single chip integrating billions of microscopic electronic components.

Stable mass production of these advanced devices requires nondestructive technologies capable of measuring and insulating metal films with nanoscale precision.

To meet this need, Rigaku further advanced the X-ray technologies it has cultivated over decades to develop the XTRAIA MF-3400. Among its new capabilities, the XTRAIA MF-3400 supports measurement of molybdenum, an element attracting attention as a next-generation material.

Key Features of the XTRAIA MF-3400

• Measurement capability up to double that of previous devices

  By doubling the X-ray dose and integrating a new transport system, the number of wafers measurable per hour is dramatically increased.
• Nondestructive measurement with nanoscale accuracy

  On a field as narrow as 50 µm, less than the width of a human hair, the XTRAIA MF-3400 can measure film thickness with sub-nanometer precision finer than the thickness of a single atom.
• Multiple analyses on a single device

  The XTRAIA MF-3400 incorporates three analytical functions using X-rays: fluorescent X-rays, X-ray reflectance, and X-ray diffraction. Measurement can be automated by registering optimal conditions in recipes, tailored to objectives including ultra-thin-film structure, thickness, or crystallinity.

Track Record and Prospects

KIOXIA Corporation and KIOXIA Iwate Corporation have decided to implement the XTRAIA MF-3400 into mass-production lines for 3D NAND flash memory¹. The device is also expected to be used in next-generation memory production, where high capacity and high data transfer rates are essential and mass production adoption is imminent.

Moreover, manufacturers of DRAM² and logic semiconductors³ are also expected to adopt the XTRAIA MF-3400. Combines with its predecessor model, Rigaku anticipates net sales to exceed JPY 6 billion in FY2026.

A range of modules can be selected for the XTRAIA MF-3400 tailored to different applications. This flexibility enables each manufacturer to construct the measurement environment that is ideal for its manufacturing processes. Leveraging these strengths in versatility and scalability, Rigaku will continue to develop applications in new material and process fields, aiming for sustainable growth of 20% per year in FY2027 and beyond for both model series.

1. Memory media that use a 3D structure to achieve high capacity, high speed and low power consumption

2. Volatile main-memory devices that hold data temporarily; high-speed operation is a key feature

3. Semiconductors used for processes such as calculation and control

Product Details

https://rigaku.com/products/semiconductor-metrology/xrr-edxrf-and-optical-tools/xtraia-mf-3400?setLang=english　
